- 126 -
On entering the option enter a desired value [0% - 100%]. Upon entering a
particular value the brightness changes respectively and the program returns
to the previous menu level.
23.7. Touch screen display calibration
Touch screen display calibration is required if during operation a user spots
incorrect reaction of the touch panel.
Procedure:
•
Enter submenu < Others>
•
Select parameter < Touch screen display calibration> which opens an
editing window,
•
Use finger or a thin (but not sharp edged) and soft stylus to press and
hold a display area occupied by a cross. After pressing the fifth cross in
sequence, accept the changes by pressing
key.
Caution:
The process can be aborted by pressing Esc key on an external keyboard
connected to the moisture analyzer’s terminal. Other means of aborting
calibration process are not available, and if initiated, calibration has to be
completed.
23.8. Level control
Moisture analyzer MA 3Y series may feature an Automatic Level Control
system or an external level indicator.
Leveling procedure with use of the Automatic Level Control system:
•
Enter submenu < Others >
•
Select parameter < Level control> which opens an editing window,
•
Select one of available options:
o
None – level indicator is not displayed, the moisture analyzer does not
control level status,
o
Active – level indicator is displayed, the moisture analyzer alerts on
level change by changing colour of level indicator (green → level status
OK., red → level status lost)
o
Active with lock – level indicator is displayed , the moisture analyzer
alerts on level change by changing colour of level indicator (green →
level status OK., red → level status lost). If level indicator is red, the
display also shows an alert – no Level - , and blocks weighing function
until level status is restored.
