39
7.2.11 Analog Mode
Use the Analog Mode setting to activate the analog input. If you are not using the analog input,
setting Analog Mode to Inactive will prevent errant operation if [MODE] is pressed accidentally.
1. Press [MENU]. Press [UP] seven times until the screen {-MENU- / ANALOG MODE} is displayed.
–MENU–
ANALOG MODE
Press [ENTER] to continue to configure the analog mode.
2. Press [UP] and the {INACTIVE} option is displayed. If you are not using the analog input to control
your DLC–XP, press [ENTER] to accept the inactive setting and return to the {–MENU–} level.
ANALOG MODE
INACTIVE
3. Press [UP] and the {ACTIVE} option is displayed. If you are using the analog input to control your
DLC, press [ENTER] to accept the active setting.
ANALOG MODE
ACTIVE
4. The {SAMPLE SIZE / 10} screen is displayed. Use [UP] and [DOWN] to set the number of samples
taken from the 4-20mA input to average. The DLC–XP will adjust its output to in accordance with
the average of the number of samples you set here. The DLC–XP samples the port every .25 seconds.
You may enter a value in the range of 1 to 100 samples.
Rule of Thumb: Increase the number of samples to smooth out a noisy input. Decrease the number
of samples to cause the DLC to track more closely a rapidly changing signal.
SAMPLE SIZE
10
5. The {UPDATE EVERY / 20 SAMPLES} screen will appear. Use [UP] and [DOWN] to set how
often the DLC will adjust to the current average value. The default value (20) causes the DLC to
adjust every 20 samples or every 5 seconds (20 * .25 = 5). You may enter a value in the range of 1 to
100 samples.
Rule of Thumb: Increase the number of samples if the input is not changing rapidly. Decrease the
number of samples if it is changing rapidly.
UPDATE EVERY
20 SAMPLES
6. Press [ENTER] to accept the setting and return to the { -MENU- } level.
7.2.12 Security
The DLC is capable of three modes of security:
1. None (OFF)
2. Tamper Proof
3. Calibration
With Tamper Proof security active, the DLC–XP will lockout all of the front panel keys with the
exception of [MOTOR]. To use any key you must first enter a four digit Personal Identification
Number (PIN). Successful entry of a PIN allows you to access all functions without PIN re-entry.
With Calibration security set, the DLC–XP will lockout only [CAL]. To use [CAL] you must first
enter your PIN. Successful entry of a PIN allows the user to access the [CAL] menu.
The security mode becomes active after 5-minutes of keypad in-activity.
