Mirror Port
6-24
The software displays a list of ports, similar to the following
screen (some ports have been named in the example):
4. Select Return to Main Menu...
5. Go to your monitoring device to see the traffic.
Please select a port:
Port 1-Room 1148 Port 2-Room 1149
Port 3-Room 1150 Port 4-Room 1151
Port 5 Port 6
Port 7 Port 8
Port 9 Port 10
Port 11 Port 12
Port 13 Port 14
Port 15 Port 16
Port 17 Port 18
Port 19 Port 20
Port 21 Port 22
Port 23 Port 24
Port 26-Uplink Port A Port 27-Uplink Port B
Return to Port Mirroring Configuration...
