AT-S20 User’s Guide
6-27
Selecting a port number, for example, 1 , from the list displays the
port configuration screen for Port 1, as shown in Figure 6-25.
Figure 6-25 Port Configuration for Port 1
The following options at the top of the screen are for information
only.
❑ Link State indicates the presence or absence of a physical link
on the port.
❑ Port State indicates if the port has been enabled, disabled,
blocked, affording, or listening. The state changes depending
on software or user intervention.
Normal means the port is ready but not necessarily active.
Disabled means someone has manually disabled the port
using the Omega software.
Partitioned means the software has detected an error in
the network and therefore automatically disables the port to
prevent the error from propagating.
❑ Transmission Mode indicates the speed and direction by
which packets can be transmitted either by enabling auto-
negotiate, (10 or 100 Mbps) half- duplex (one direction only),
or full-duplex (both directions simultaneously.
Accounting
Port 1
Link State: Online
Port State: Enabled
Transmission Mode: Half duplex
Enable this port
Disable (partition) this port
Auto negotiate
Full duplex
Half duplex
Store-and-forward
Cut-through (fragment-free)
Transmit pacing enabled
No transmit pacing
Port Name
Return to Port Status Menu ...
