Getting Started with Local Omega
2-2
6WDUWLQJ#DQ
2PHJD#6HVVLRQ
Once you have established a connection to the switch, the Omega
Main Menu displays.
The banner reflects the name of your switch. This example shows
that the AT-3714FXL switch is operating and the switch name is
Accounting.
Figure 2-1 Omega Main Menu (AT-3714FXL)
By selecting System Configuration from the main menu, the
following screen displays. The default settings are always in bold
print on the screen.
Figure 2-2 System Configuration Menu
Allied Telesyn AT-3714FXL Ethernet Switch
Accounting
Main Menu
Port status and configuration
Ethernet statistics
Administration
System configuration
Traffic/Port Mirroring
Virtual LANs
Bridging
MAC Address Table
Quit
Allied Telesyn AT-3714FXL Ethernet Switch
Accounting
Main Menu
Password: Null (not configured)
Timeout: 5
Local Omega Enabled
Disabled Local Omega
Remote Omega Enabled
Remote Omega Disabled
Web-based Omega Enabled
Exclude Web-based omega
Return to system Configuration Menu ...
