AT-S20 User’s Guide
4-11
1DPLQJ#WKH#3RUW
0HQX1#
Port status and configuration>
Number>
Depending on the model, the switch has the following ports,
identified numerically, as listed in Table 4-1.
Because of the number of ports, you may find it more convenient to
manage the ports if you assign a unique name to each port. You can
associate a port number with a specific user or a location (for
example,
Port 1 to Room 1147 ).
1. Select Port status and configuration to display the list
of ports.
2. Select a port number from the list.
Table 4-1 Port Numbering
Switch Port # Port Type
AT-3726XL,
AT-3726 1-24 10Base-T
25 Remote management port for Omega
26 (Uplink port A) 10/100Base-TX
27 (Uplink port B) Optional MDA (TX or FX)
AT-3716XL 1-16 10Base-T
17 Remote management port for Omega
18 (Uplink port A) 10/100Base-TX
19 (Uplink port B) Optional MDA (TX or FX)
AT-3714FXL,
AT-3714F 1-12 10Base-FL
13 Remote management port for Omega
14 (Uplink port A) 100Base-FX
15 (Uplink port B) Optional MDA (TX or FX)
