AT-S20 User’s Guide

6-9

$GG2'HOHWH#6WDWLF

0$&#$GGUHVVHV

DQG#6HOHFWLQJ

3RUWV#IRU

0XOWLFDVWV

0HQX1#

Multicast addresses> Add MAC address>

Ports for Multicasts

Multicast addresses are a type of static address. When you clear the
static address table, all multicast addresses are discarded. However, if
you add a multicast address, this address appears in the static
address table.

Note

You add or delete a MAC address from the Muticast Addresses menu.

Figure 6-10 Muticast Addresses (Add/Delete MAC Addresses)

1. Select

Multicast addresses, Add MAC address

Note

Prior to MAC addresses being added, you must enter both the MAC
address and ports to receive multicast packets.

Add Static MAC Address Menu

Accounting

MAC Addresses

MAC Address

Ports for Multicast Packets

0100F4 010243

14,15

0100F4 397492

all

0100F4 070697

7,8

0100F4 643476

2,3

0100F4 365454

4,5

Add MAC address

Null (not configured)

Ports for multicast

Null (not configured)

(Example: 1, 3, 8, or all)

Delete MAC address

Null (not configured)
