MAC Address Table
6-4
6KRZ#$OO#0$&
$GGUHVVHV
Select MAC Address Table> Show all MAC addresses .
Figure 6-3 Show All MAC Addresses
6KRZ#%\#3RUW
0$&#$GGUHVVHV
0HQX1#
By port MAC addresses
1. Select MAC Address Table from the main menu. The MAC
address menu displays.
2. To learn the MAC address of a specific port, select By port MAC
addresses .
3. Select a specific port number to learn the MAC addresses for that
port. The following screen displays as an example, Port 5’s MAC
addresses.
Figure 6-4 By Port MAC Address (Port 5)
MAC Address Table
Accounting
MAC Addresses - Page 1
MAC Address Port MAC Address Port
0000F4 010001 2 0000F4 010010 2
0000F4 010003 2 0000F4 010011 2
0000F4 010004 2 0000F4 010011 2
0000F4 010005 2 0000F4 010013 2
0000F4 010006 2 0000F4 010014 2
0000F4 010007 2 0000F4 010015 2
Next page
Return to MAC Address Menu ...
MAC Address Table
Port 5
MAC Addresses - Page 1
MAC Address MAC Address MAC Address MAC Address
0000F4 010203 0000F4 010205 0000F4 010211 0000F4 010209
0000F4 010212 0000F4 010206 0000F4 010235 0000F4 010208
0000F4 010211 0000F4 010207 0000F4 010245 0000F4 010207
0000F4 010214 0000F4 010208 0000F4 010255 0000F4 010206
0000F4 010214 0000F4 010209 0000F4 010265 0000F4 010205
0000F4 010216 0000F4 010201 0000F4 010275 0000F4 010204
Next page
Return to Port Selection Menu...
