AT-S20 User’s Guide
6-7
6KRZ#3HU#3RUW
6WDWLF#0$&
$GGUHVVHV
0HQX1#
MAC Address Table>Per Port Static MAC
Addresses> Port number
See Figure 6-7 and Figure 6-8.
Figure 6-7 Per Static MAC Addresses
The static MAC addresses for Port 2 display, as shown in Figure 6-8.
Figure 6-8 Per Port Static MAC Address (Port 2)
Port Selection Menu
Accounting
Port 1 Port 2
Port 3 Port 4
Port 5 Port 6
Port 7 Port 8
Port 9 Port 10
Port 11 Port 12
Port 13 Port 14
Port 15 Port 16
Port 17 Port 18
Port 19 Port 20
Port 21 Port 22
Port 23 Port 24
Port 26 - Uplink Port A Port 27 - Uplink Port B
Return to MAC Address Menu ...
Add MAC Address Menu
Accounting
Port 2
MAC Addresses MAC Address MAC Address MAC Address
0000F4 010203 0000F4 010205 0000F4 010211 0000F4 010209
0000F4 010212 0000F4 010206 0000F4 010235 0000F4 010208
0000F4 010211 0000F4 010207 0000F4 010245 0000F4 010207
0000F4 010214 0000F4 010208 0000F4 010255 0000F4 010206
0000F4 010214 0000F4 010209 0000F4 010265 0000F4 010205
0000F4 010216 0000F4 010201 0000F4 010275 0000F4 010204
Add MAC address Null (not configured)
Delete MAC address Null (not configured)
Next page
Return to Port Selection Menu...
