AT-S20 User’s Guide
7-3
5XQQLQJ#'LDJQRVWLFV
0HQX1
Administration> Diagnostics
Select Diagnostics from the System Administration Menu to
display the Diagnostics screen. The example in Figure 7-1 shows the
Diagnostics screen on a switch named Accounting.
Figure 7-1 Diagnostics Screen
The Diagnostics Menu allows you to run a limited set of diagnostics
test on the switch. There are only two results on a diagnostics test:
Good or Failed .
You also see the following information:
❑ The switch model and version number
❑ The switch’s MAC address
❑ The software model and version number
❑ The type of MDA (applique) if installed and whether a MAU is
installed (Medium Attachment Unit)
❑ The time the switch has been up and running
Accounting
Allied Telesyn AT-3714FXL
MAC Address 0000F4 010203 RJ45/MII Applique, MAU
AT-S20 Ethernet Switch Software: Version 3.0 981104
Running 2 days, 20 minutes, 10 seconds
Diagnostics Results:
Flash PROM Good
RAM Good
Serial Interface Good
Optional Extended Diagnostic Tests:
Extended Diagnostic Test will disrupt normal system
These tests should be run only when the network is
inactive.
Run Extended Diagnostic Tests now? (Yes or No):
