2-1
&KDSWHU 5
*HWWLQJ#6WDUWHG#ZLWK#/RFDO#DQG#5HPRWH#2PHJD
*HWWLQJ#6WDUWHG#ZLWK#/RFDO#2PHJD
To locally managing your switch, simply connect a terminal or PC
directly to the switch’s RS232 port to access the Omega menus. See
the following sections.
&RQILJXULQJ#
7HUPLQDO
(PXODWRU
3URJUDP
To set the terminal emulator program, do the following:
1. Access the terminal emulator program on your PC (VT100) and set
the following:
❑ Data bits to 8
❑ Stop bits to 1
❑ Parity to None
❑ Full-duplex (using straight-through cable)
❑ Autobaud
Note
The diagnostics that run during the system boot output only at 9600
bps. Therefore, Allied Telesyn recommends this speed setting.
2. Press several times to ensure baud autoconfiguration.
