Configuring Device Security
Defining Access Control
Page 80
Adding ACE Rules
1. Click Network Security > MAC Based ACL. The MAC Based ACL Page opens.
2. Click the Add ACE button. The Add MAC Based ACE Page opens.
Figure 45: Add MAC Based ACE Page
3. Define the fields.
4. Click Apply. The MAC Based ACE rule is defined and the device is updated.
5. Click Save Config on the menu to save the changes permanently.
To modify the MAC Based ACL configuration:
1. Click Network Security > MAC Based ACL. The MAC Based ACL Page opens.
2. Click Modify. The Add MAC Based ACE Page opens:
3. Define the fields.
4. Click Apply. The MAC Based ACL configuration is defined, and the device is updated.
5. Click Save Config on the menu to save the changes permanently.
Defining IPv4 Based ACL
The IPv4 Based ACL Page contains information for defining IPv4-based ACLs, including defining the ACEs for
IPv4-based ACLs.
1. Click Network Security > IPv4 Based ACL. The IPv4 Based ACL Page opens.
