Configuring LLDP
Page 187
Defining LLDP MED Port Settings
The LLDP MED Port Settings Page contains parameters for assigning LLDP network policies to specific ports. To
configure LLDP MED port settings:
1. Click LLDP > LLDP-MED Port Settings. The LLDP MED Port Settings Page opens:
Figure 131:LLDP MED Port Settings Page
The LLDP MED Port Settings Page contains the following fields:
• Unit No. — Indicates the stacking member’s ports for which the LLDP-MED port settings are displayed.
• Port — Specifies the list of ports to which LLDP-MED network policy can be attached.
• LLDP MED Status —Indicates the LLDP-MED port status, the possible field values are:
– Enable — Indicates that LLDP-MED is enabled on the port.
– Disable — Indicates that LLDP-MED is disabled on the port.
• Network Policy — Indicates LLDP MED network policy attached to the port.
• Location —Indicates if location identification is transmitted in LLDP packets.
• PoE — Indicates if PD-PSE information is transmitted in LLDP packets.
