Configuring Services
Page 204
As a default the Bandwidth Page opens displaying the port options. The fields are identical when displaying the
trunk CoS. The Bandwidth Page contains the following fields:
• Select the interfaces displayed in the table.
– Ports of Unit — Specifies the port and stacking member for which the bandwidth settings are displayed.
– Trunk — Specifies the trunk for which the bandwidth settings are displayed.
• Interface — Indicates the interface for which this bandwidth information is displayed.
• Ingress Rate Limit — Indicates the traffic limit for ingress interfaces. The possible field values are:
– Status — Enables or disables rate limiting for ingress interfaces. Disable is the default value.
– Rate Limit — Defines the rate limit for ingress ports. Defines the amount of bandwidth assigned to the
interface. The available values are 62 Kbps - 1 Gbps (for FE ports, the maximum value equals the
maximum port speed).
• Egress Shaping Rates — Indicates the traffic shaping type, if enabled, for egress ports. The possible field
values are:
– Status — Indicates the egress shaping rate status. The default status is Disabled.
– CIR — Defines Committed Information Rate (CIR) as the queue shaping type. The possible field values
are 0-62.5 Mbps.
– CBS — Defines Committed Burst Size (CbS) as the queue shaping type. CbS is supported only on GE
interfaces. The possible field value is 4 KB - 16 MB.
2. Select the port/unit or trunk.
3. Select the interfaces to configure.
