x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide
55
*
The Maximum Power Level Output levels reflect the loss introduced by a 100
meter Ethernet cable between the Power Source Equipment (PSE) and the
Power Device (PD).
A port connected to a network node that is not a PD functions as a regular
Ethernet port, without PoE+. The PoE+ feature remains enabled on the
port but no power is delivered to the device.
Note
On the 24 port x610 PoE+ switches, the PoE+ power supplied from
from ports 21R, 22R, 23R and 24R is unaffected by insertion of a
SFP module into the corresponding SFP combo port.
On the 48 port x610 PoE+ switches, the PoE+ power supplied from
from ports 47R and 48R is unaffected by insertion of a SFP module
into the corresponding SFP combo port.
Power Capacity Either a 250W (AT-PWR250), 800W (AT-PWR800) or a 1200W
(AT-PWR1200) power supply (PSU) can be installed in the x610-24Ts-
POE+, x610-24Ts/X-POE+, x610-48Ts-POE+ and x610-48Ts/X-POE+
switches. The model of PSU that is installed determines the maximum
number of PoE+ ports that are supported on the switch. The following
three tables show the maximum number of PoE+ and PoE ports supported
on the switch, depending on the model of PSU installed. Note that the
numbers in these tables only provide the maximum number of PoE+ and
PoE ports supported and that there are many combinations of PoE+ and
PoE ports that are supported.
Table 13. PoE+ Ports Supported With AT-PWR250 Power Supply Unit
Model
Available
PoE Power
IEEE 802.3at
Class 4 (30W)
IEEE 802.3af
Class 3
(15.4W)
x610-24Ts-POE+ None None None
x610-24Ts/X-POE+ None None None
x610-48Ts-POE+ None None None
x610-48Ts/X-POE+ None None None
