x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide
117
Table 21 lists the pin signal definitions when a port operating at 1000
Mbps.
Table 21. Pin Signals - 1000 Mbps
Pinout
Pair
1
Pair 1 +
2
Pair 1 -
3
Pair 2 +
4
Pair 3 +
5
Pair 3 -
6
Pair 2 -
7
Pair 4 +
8
Pair 4 -
