Combo Ports
On the 24 port x610 Series switches, the 10/100/1000Base-T ports 21R to
24R are paired with the four SFP slots to form four combo ports, as listed
in Table 3.
On the x610-48Ts and x610-48Ts-POE+ switches, the
10/100/1000Base-T ports 47R and 48R are paired with the four SFP slots
to form four combo ports, as listed in Table 4.
On the x610-48Ts/X and x610-48Ts/X-POE+ switches, the
10/100/1000Base-T ports 47R and 48R are paired with the two SFP slots
to form two combo ports, as listed in Table 5.
The 10/100/1000Base-T ports are identified with the letter “R” for
“Redundant” as part of their number on the faceplate of the unit.
Table 3. 10/100/1000Base-T Ports Matched with SFP Slots on 24 Port
Switches
Ports and Slots
Port 21R with SFP slot 21
Port 22R with SFP slot 22
Port 23R with SFP slot 23
Port 24R with SFP slot 24
Table 4. 10/100/1000Base-T Ports Matched with SFP Slots on x610-48Ts
and x610-48Ts-POE+ Switches
Ports and Slots
Port 45R with SFP slot 45
Port 46R with SFP slot 46
Port 47R with SFP slot 47
Port 48R with SFP slot 48
Table 5. 10/100/1000Base-T Ports Matched with SFP Slots on
x610-48Ts/X and x610-48Ts/X-POE+ Switches
Ports and Slots
Port 47R with SFP slot 47
Port 48R with SFP slot 48
