19
Chapter 1
Overview
This chapter contains the following sections:
ˆ
“Introduction” on page 20
ˆ
“Switch Descriptions” on page 21
ˆ
“10/100/1000Base-T Ports” on page 29
ˆ
“SFP and SFP+ Transceiver Slots” on page 31
ˆ
“Combo Ports” on page 33
ˆ
“SD Card Slot” on page 35
ˆ
“Port LEDs” on page 36
ˆ
“System STATUS LEDs” on page 41
ˆ
“STACK LEDs” on page 43
ˆ
“Secure Digital (SD) LED” on page 45
ˆ
“Terminal Port” on page 46
ˆ
“Power Supplies” on page 47
ˆ
“Redundant Power Supplies” on page 49
ˆ
“AT-LBM (Loop Back) Module” on page 51
ˆ
“VCStack Stacking Module” on page 52
ˆ
“AC Power Connector” on page 53
ˆ
“Power Over Ethernet Plus (PoE+)” on page 54
Note
Do not begin the installation procedures in this guide until you have
read the AlliedWare Plus
Operating System Software Release Notes
that are included with the latest release of the AlliedWare Plus
Operating System Software
.
