Allied Telesis AT-SBx31CFC960 User Manual
Page 97
SwitchBlade x3112 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
97
Figure 37. Rack Mounting Bracket Locations
Figure 38. Rack Bracket Locations for Reverse Position of Chassis
Factory Installed - Flush with Rack Rails
A
B
C
D
E
“Dim X”
“Dim X”
“Dim X”
“Dim X”
Front panel facing
towards the rear
of the rack
F
