SwitchBlade x3112 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
215
2. Connect the other end of the cable to an RS-232 port on a terminal or
personal computer with a terminal emulation program.
3. Configure the VT-100 terminal or terminal emulation program as
follows:
 Baud rate: 115,200 bps
 Data bits: 8
 Parity: None
 Stop bits: 1
 Flow control: None
Note
The port settings are for a DEC VT100 or ANSI terminal, or an
equivalent terminal emulator program.
4. Press Enter. You are prompted for a user name and password.
5. Enter the default user name and password. They are “manager” and
“friend” (without the quotes), respectively
Note
User names and passwords are case sensitive.
The local management session starts and the command line interface
(CLI) prompt is displayed.
Entering the
Management
Software
Commands
To confirm the operations of the chassis with the commands in the
management software, perform the following procedure:
1. To display the status of the power supplies, enter the SHOW PSU
command.
An example of the status information is shown in Figure 150 on page
216. The power supplies are operating normally when the states are
UP-UP. If there is a problem with a power supply, refer to “AT-
SBxPWRSYS1 and AT-SBxPWRPOE1 AC Power Supplies” on
page 234 or “AT-SBxPWRSYS1 DC Power Supply” on page 236 for
troubleshooting suggestions.
