Figure 40: installing the rack mount screws – Allied Telesis AT-SBx31CFC960 User Manual
Page 100
Chapter 5: Installing the Chassis in an Equipment Rack
100
Figure 40. Installing the Rack Mount Screws
5. Tighten all eight screws to secure the chassis to the equipment rack.
Allied Telesis recommends tightening the screws to 10 inch-lbs.
6. Go to “Removing the Shipping Brace” on page 101.
First two screws
Bottom Screw
Center Screw
Top Screw
Bottom Screw
Center Screw
Top Screw
installed
