Chapter 6: Installing the Power Supplies
116
Figure 56. Verifying the AT-SBxPWRPOE1 AC Power Supply
5. Raise the locking handle on the AT-SBxPWRPOE1 AC Power Supply,
as shown Figure 57.
Figure 57. Raising the Handle on the AT-SBxPWRPOE1 AC Power
Supply
6. Align and insert the AT-SBxPWRPOE1 Module into slot A or B. Figure
58 on page 117 shows the power supply being installed in slot A.
Caution
The AT-SBxPWRPOE1 AC Power Supply will not work in slot C or
D.
