Chapter 8: Installing the Transceivers and Cabling the Ports
156
Note
Do not remove a dust plug from an SFP+ slot if you are not installing
a transceiver at this time. A dust plug protects the line card from dust
contamination.
2. Orient the SFP+ transceiver with the handle on top, as shown in
Figure 95.
Figure 95. Handle on SFP+ Transceiver
3. Slide the transceiver into the slot until it clicks into place, as shown in
Figure 96.
Figure 96. Installing an SFP+ Transceiver in the AT-SBx31XS6 Line Card
Handle
