Figure 34: rack mounting hole locations – Allied Telesis AT-SBx31CFC960 User Manual
Page 93
SwitchBlade x3112 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
93
Figure 34. Rack Mounting Hole Locations
5. After installing the two screws in the equipment rack, go to “Unpacking
the AT-SBx3112 Chassis” on page 94.
6.4 mm (.25 in)
Screw head
Top screw hole of the lowest 1/2” hole pattern
away from rack
