ADV/MATE/AGS/TIMERS
lsstart timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS
lsstop timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS
vdcstop timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS
exstop timer 0 min
DOWN UP
The 2hr vs time 120 min screen counts down
the 2-hour voltage start set point. Pressing the
soft key leads to the 2 min vs time
screen.
The 2 min vs time screen counts down the 2-min-
ute voltage start set point. Pressing the
soft key leads to the lsstart timer screen.
This screen displays the load start delay timer
which is adjustable up to 240 minutes, counting
down. The user determines how many minutes
the AC loads must remain above the load start
kw set point before starting the generator. Press
the soft key to view the next TIMERS
screen
The lsstop timer screen counts down the time the
AC load must remain below the load stop kw be-
fore the generator stops. Press the soft
key to view the vdcstop timer screen.
The vdcstop timer counts down the amount of
time a DC generator is allowed to run. Press
the soft key to view the last TIMERS
screen.
The exstop timer screen displays the amount of
time the generator runs during an exercise period
(1-240 minutes). Press the soft key to
open the end of TIMERS screen.
ADV/MATE/AGS/TIMERS
2hr vs time 120 min
DOWN UP
ADV/MATE/AGS/TIMERS
2 min 2 min
vs time
DOWN UP
