111
STATUS/FX/WARN---P00
acin voltage NO
too low
DOWN UP TOP PORT
STATUS/FX/WARN---P00
temperature No
sensor fault
DOWN UP TOP PORT
STATUS/FX/WARN---P00
internal comm No
error detected
DOWN UP TOP PORT
STATUS/FX/WARN---P00
internal fan N0
failure detected
DOWN UP PORT
STATUS/FX/WARN---P00
airtemp 204
DOWN UP PORT
STATUS/FX/WARN---P00
fettemp 204
DOWN UP PORT
STATUS/FX/WARN---P00
captemp 204
DOWN UP PORT
STATUS/FX/WARN---P00
ac input No
current exceeds max
DOWN UP TOP PORT
STATUS/FX/WARN------
end of warnings
menu
UP TOP STATUS
FX DISCONNECT REASONS
STATUS/FX/PAGE2----------
choose category:
PG1 ERROR WARN PG3
STATUS/FX/PAGE3-----
choose category:
PG2 DISCON SELL MAIN
STATUS/FX/DISCON-P00
acin freq No
too high
DOWN STATUS PORT
STATUS/FX/DISCON-P00
acin freq No
too low
DOWN UP STATUS PORT
STATUS/FX/DISCON-P00
acin voltage No
> max
DOWN UP TOP PORT
STATUS/FX/DISCON-P00
acin voltage No
< min
DOWN UP TOP PORT
FX SELL SCREENS
STATUS/FX/PAGE3-----
choose category:
PG2 DISCON SELL MAIN
STATUS/FX/DISCON-----
end of DISCON menu
UP TOP STATUS
STATUS/FX/SELL---P00
stop sell 255
reason
STATUS PORT
MAIN--------------------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS------------------------
choose device:
FX CC DC MAIN
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
STATUS/CC/MODE--P00
charger mode: Absorb
DOWN STATUS PORT
STATUS/CC/MODE--P00
aux relay mode:
Vent Fan
DOWN UP TOP PORT
CHARGE CONTROLLER
MODES
STATUS/CC/MODE--P00
aux relay state: ON
DOWN UP TOP PORT
STATUS/CC/MODE--------
end of mode menu
UP TOP STATUS
CHARGE CONTROLLER
METERS
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
mode: Absorb P01
in 11.2 vdc 0 adc
out 14.4 vdc 0 adc
DOWN STATUS PORT
STATUS/CC/METER--P00
charger 0 w
watts
DOWN UP TOP PORT
STATUS/CC/METER---P00
charger 0.0 kwh
kwhrs
DOWN UP TOP PORT
STATUS/CC/METER---P00
charger +000 adc
amps dc
DOWN UP TOP PORT
STATUS/CC/METER---P00
battery 14.4 vdc
voltage
DOWN UP TOP PORT
STATUS/CC/METER---P00
charger 0 ah
amp hour
DOWN UP TOP PORT
