Outback Power Systems MATE2 System Controller and Display Installation and User Manual User Manual
Page 114
114
SETUP/FX/SEARCH--P00
search 60 cycles
pulse spacing
DOWN INC DEC PORT
SETUP/FX/SEARCH---------
search setup
completed
TOP SETUP MAIN
SETUP/FX------------
choose category:
SRCH INPUT MAIN
SETUP/FX/INPUT---P00
ac1/grid 48 aac
limit
DOWN INC DEC PORT
SETUP/FX/INPUT---P00
ac transfer GRID
control
DOWN GRID GEN PORT
SETUP-----------------------
choose device:
FX MATE
SETUP/FX/INPUT------
input setup
completed
TOP SETUP MAIN
MAIN-------------------------
6:54:42PM
SUM STATUS SETUP ADV
SETUP/FX/INPUT---P00
ac2/gen 50 aac
limit
DOWN INC DEC PORT
MATE SETUP
MATE DATE & TIME
SETUP/MATE/PAGE1----
mate code rev: 4.1.3
choose category:
CLOCK CNT GLOW PG2
SETUP/MATE/CLOCK------
Tu 12/10/02
4:00:22P
BACK DATE TIME
SETUP/MATE/PAGE1----
mate code rev: 4.1.3
choose category:
CLOCK CNT GLOW PG2
SETUP/MATE/PAGE1----
mate code rev: 4.1.3
choose category:
CLOCK CNT GLOW PG2
MATE GLOW (BACKLIGHT)
SETUP/MATE/PAGE1----
mate code rev: 4.1.3
choose category:
CLOCK CNT GLOW PG2
SETUP/MATE/CNT----------
contrast: 30%
BACK INC DEC
MATE CONTRAST
SETUP/MATE/GLOW------
backlight controls
BACK LEVEL MODE TIME
MATE SUMMARY
SETUP/MATE/PAGE1----
mate code rev: 4.1.3
choose category:
CLOCK CNT GLOW PG2
SETUP/MATE/PAGE2----
choose category:
PG1 SUMRY COMM PG3
SETUP/MATE/SUMMARY-
summary control
BACK TYPE DELAY ROLL
MATE
COMM(UNICATIONS)
SETUP/MATE/COMM-----
choose category:
BACK REPOLL PC DEBUG
SETUP/MATE/SUMMARY-
summary control
BACK TYPE DELAY ROLL
SETUP/MATE/SUM/TYPE-
summary Roll
screen tpe
BACK INC DEC
SETUP/MATE/SUM/DELAY
sum screen: 20 mins
delay time
BACK INC DEC
SETUP/MATE/SUMMARY-
summary control
BACK TYPE DELAY ROLL
SETUP/MATE/SUM/ROLL-
sum screen: 10 secs
roll rate
BACK INC DEC
PRESS TWICE
SETUP/MATE/PAGE2-------
choose category:
PG1 SUMRY COMM PG3
Searching
for devices
CC FOUND
SETUP/MATE/COMM-----
choose category:
BACK REPOLL PC DEBUG
AFTER A DEVICE IS FOUND, choose
category SCREEN RETURNS
SETUP/MATE/COMM/PC-
pc communications: OFF
BACK OFF ON
SETUP/MATE/COMM-----
choose category:
BACK REPOLL PC DEBUG
DEBUG opens comm errors screen
