STATUS/CC/METER-—P00
panel 11 vdc
voltage
DOWN UP TOP PORT
STATUS/CC/METER-—---
end of meter menu
UP TOP STATUS
CHARGE CONTROLLER SET
POINTS
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
STATUS/CC/SETP------P00
Absorb 14.4 vdc
DOWN STATUS PORT
STATUS/CC/METER-P00
CC firmware revision
001.009.003
DOWN UP TOP PORT
STATUS/CC/SETP------P00
Float 13.6 vdc
DOWN UP TOP PORT
STATUS/CC/SETP----------
end of setpoint
menu
UP TOP STATUS
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
STATUS/CC/LOGS1--P01
TODAY 0AH 00.0 kWH
11Vp 00.0Ap 0.00kWp
DOWN DAY- DAY+ PORT
STATUS/CC/LOG2---P01
TODAY battery
max 14.5V min 14.4V
DOWN DAY- DAY+ PORT
STATUS/CC/LOG3---P01
TODAY absorb float
00:00 00:00
DOWN DAY- DAY+ PORT
STATUS/CC/LOG4----------
end of cc logs display
TOP STATUS
STATUS/CC/PAGE 2-------
PG1 LOGS STAT MAIN
CHARGE CONTROLLER
LOGS
CHARGE CONTROLLER
STATISTICS
STATUS/CC/STAT------P01
maximum battery
21.1 vdc
DOWN UP PORT
STATUS/CC/PAGE 2-------
PG1 LOGS STAT MAIN
STATUS/CC/STAT------P01
maximum wattage
0 W
DOWN UP TOP PORT
STATUS/CC/STAT------P01
max voc 19.0 vdc
DOWN UP TOP PORT
STATUS/CC/STAT------P01
voc 0.0 vdc
DOWN UP TOP PORT
STATUS------------------------
choose device:
FX CC DC MAIN
MAIN-------------------------
6:54:42PM
SUM STATUS SETUP ADV
FLEXnet DC
STATUS
STATUS/CC/STAT------P01
total kWH DC
307
DOWN UP TOP PORT
STATUS/CC/STAT------P01
total kAH
0.0
DOWN UP TOP PORT
STATUS/CC/STAT------P01
end of CC stats
menu
UP TOP STATUS
STATUS/DC/PAGE 1--------
STATS
METER SHUNT BATT PG2
A: A 0kW
B: A 0kW
C: A 0kW
DOWN STATUS
A: AH 0kWH
B: AH 0kWH
C: AH 0kWH
DOWN UP TOP
METER/DC/SHUNT A
removed
0AH 0.000kWH
DOWN UP TOP
METER/DC/SHUNT A
charged
0AH 0.000kWH
DOWN UP TOP
METER/DC/SHUNT B
removed
0AH 0.000kWH
DOWN UP TOP
METER/DC/SHUNT B
charged
0AH 0.000kWH
DOWN UP TOP
METER/DC/SHUNT C
charged
0AH 0.000kWH
DOWN UP TOP
METER/DC/SHUNT C
removed
0AH 0.000kWH
DOWN UP TOP
