117

ADV/FX/STACK---------P00

stack 3PH Master

phase

DOWN INC DEC PORT

ADV/FX/STACK---------P00

power save level 0

master adjust only

DOWN INC DEC PORT

ADV/FX/STACK---------P00

power save level 1

slave adjust only

DOWN INC DEC PORT

ADV/FX/STACK-------------

stacking setup

completed

TOP ADV MAIN

ADV/FX/STACK---------P00

stack 3PH Slave

phase

DOWN INC DEC PORT

FX SELL

ADV/FX/PAGE3-------------

choose category:

PG2 AUX STACK PG4

ADV/FX/PAGE4-------------

choose category:

PG3 SELL CAL MAIN

ADV/FX/SELL----------P00

sell re 23.6 vdc

volts

DOWN INC DEC PORT

ADV/FX/SELL----------P00

grid tie IEEE

window

DOWN IEEE USER PORT

ADV/FX/SELL-----------P00

grid tie ---

authority

DOWN INC DEC PORT

ADV/FX/SELL---------P00

selling setup

Completed

TOP ADV MAIN

FX CALIBRATE

ADV/FX/PAGE4-------------

choose category:

PG3 SELL CAL MAIN

ADV/FX/CALIBRATE-P00

vac input 120 vac

adjustment

DOWN INC DEC PORT

ADV/FX/CALIBRATE-P00

battery vdc 25.4 vdc

adjustment

DOWN INC DEC PORT

ADV/FX/CALIBRATE-------

calibration setup

completed

TOP ADV MAIN

ADV/FX/CALIBRATE-P00

vac output 120 vac

adjustment

DOWN INC DEC PORT

AUX

CHARGE CONTROLLER

MAIN--------------------------

6:54:42P

SUM STATUS SETUP ADV

ADV/SETTINGS/WARNING

changes made could

adversely effect

system performance

ADV/PASSWORD----------

enter the password:

132

ENTER INC DEC EXIT

ADV---------------------------

choose device:

FX CC DC MATE

ADV/CC/PAGE 1------------

choose category:

ADV CHGR CCADV PG2

ADV/CC/CHGR--------------

absorb voltage 28.8v

DOWN INC DEC PORT

ADV/CC/CHGR--------------

float voltage 27.2v

DOWN INC DEC PORT

ADV/CC/CHGR-------P00

output current 80.0A

limit

DOWN INC DEC PORT

ADV/CC/CHGR--------------

end charger menu

TOP ADV MAIN

ADV----------------------------

choose device:

FX CC DC MATE

ADV/CC/PAGE 1------------

choose category:

ADV CHGR CCADV PG2

ADV/CC/ADVANCED-P01

snooze mode

<0.6 amp

DOWN INC DEC PORT

ADV/CC/ADVANCED-P01

wakeup mode

VOC change 3.0 V

DOWN INC DEC PORT

ADV/CC/ADVANCED-P01

wakeup mode

time 5 minutes

DOWN INC DEC PORT

ADV/CC/ADVANCED-P01

grid tie mode

nonGT

DOWN INC DEC PORT

ADV/CC/ADVANCED-P01

park MPP 77.0%

DOWN INC DEC PORT

ADV/CC/ADVANCED-P01

MPPT mode

auto track

DOWN INC DEC PORT

60 amp charge controller
shows 60.0A limit
