ADV/FX/PAGE2------------

choose category:

ADV GRID GEN PG3

ADV/FX/GRID---------P00

ac1/grid 108 vac

lower limit

DOWN INC DEC PORT

ADV/FX/GRID----------P00

ac1/grid 48.0 aac

input limit

DOWN INC DEC PORT

ADV/FX/GRID----------P00

ac1/grid 6 cycles

transfer delay

DOWN INC DEC PORT

ADV/FX/GRID---------------

GRID programming

completed

TOP ADV MAIN

ADV/FX/GRID----------P00

ac1/grid 140 vac

upper limit

DOWN INC DEC PORT

FX GENERATOR

ADV/FX/PAGE2-------------

choose category:

ADV GRID GEN PG3

ADV/FX/GEN-----------P00

gen input 00.5 min

connect delay

DOWN INC DEC PORT

ADV/FX/GEN-----------P00

ac2/gen 108 vac

lower limit

DOWN INC DEC PORT

ADV/FX/GEN-----------P00

ac2/gen 140 vac

upper limit

DOWN INC DEC PORT

ADV/FX/GEN-----------P00

ac2/gen 48.0 aac

input limit

DOWN INC DEC PORT

ADV/FX/GEN-----------P00

ac2/gen 60

cycles

transfer delay

ADV/FX/GEN-----------P00

ac2/gen ON

support

DOWN OFF ON PORT

ADV/FX/GEN------------------

GEN programming

completed

TOP ADV MAIN

FX AUX OUTPUT

ADV/FX/PAGE3-------------

choose category:

PG2 AUX STACK PG4

ADV/FX/PAGE2-------------

choose category:

ADV GRID GEN PG3

ADV/FX/AUX-----------P00

aux output AUTO

control

DOWN I NC DEC PORT

ADV/FX/AUX-----------P00

genalert 22.0 vdc

on setpoint

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

aux output Cool Fan

function

DOWN INC DEC PORT

ADV/FX/AUX----------P00

genalert 4 min

on delay

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

genalert 28.0 vdc

off setpoint

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

genalert 9 min

off delay

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

loadshed 22.0 vdc

off setpoint

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

ventfan 26.0 vdc

on setpoint

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

diversion 29.2 vdc

on setpoint

DOWN INC DEC PORT

ADV/FX/AUX-----------P00

diversion 30 sec

off delay

DOWN INC DEC PORT

ADV/FX/AUX----------------

aux output

setup completed

TOP ADV MAIN

ADV/FX/AUX-----------P00

ventfan off 5 min

period

DOWN INC DEC PORT

FX STACKING

ADV/FX/PAGE3-------------

choose category:

PG2 AUX STACK PG4

ADV/FX/STACK-------P00

stack 1-2PH Master

phase

DOWN INC DEC PORT

ADV/FX/STACK--------P00

stack Clasic Slave

phase

DOWN INC DEC PORT

ADV/FX/STACK--------P00

stack OB Slave L1

phase

DOWN INC DEC PORT

ADV/FX/STACK--------P00

stack OB Slave L2

phase

DOWN INC DEC PORT
