Outback Power Systems MATE2 System Controller and Display Installation and User Manual User Manual
Page 119
119
ADV/PASSWORD-------------
enter the password:
132
ENTER INC DEC EXIT
ADV/MATE/HBX------------
hbx-use 24.0 vdc
grid setpoint
DOWN ADV INC DEC
ADV----------------------------
choose device:
FX CC DC MATE
ADV/MATE/HBX------------
hbx-use 1.0 hrs
grid delay
DOWN ADV INC DEC
ADV/MATE/HBX------------
hbx-drop 26.0 vdc
grid setpoint
DOWN ADV INC DEC
ADV----------------------------
choose category:
HBX GRIDUSE AGS PG2
FLEXnet DC CHARGE
ADV/DC/CHARGE---------
return amps 10.4
DOWN INC DEC TOP
ADV/DC/CHARGE---------
battery voltage 26
DOWN INC DEC TOP
ADV/DC/CHARGE---------
charge factor 93 %
DOWN INC DEC TOP
ADV/DC/CHARGE---------
charge parameters
complete
TOP ADV MAIN
ADV----------------------------
choose device:
FX CC DC MATE
ADV/DC/PAGE1------------
choose category:
ADV BAT SHUNT PG2
ADV/DC/AUX/SOC HIGH
SOC high 90%
DOWN INC DEC TOP
ADV/DC/AUX/HIGH VOLT
high volts 29 vdc
DOWN INC DEC TOP
ADV/DC/AUX/HIGH VOLT
low volts 22.0 vdc
DOWN INC DEC TOP
ADV/DC/AUX/SOC LOW-
SOC low 59%
DOWN INC DEC TOP
ADV/DC/AUX/HI DELAY-
high setpoint delay
1 minutes
DOWN INC DEC TOP
ADV/DC/AUX/HI DELAY-
low setpoint delay
minutes
DOWN INC DEC TOP
ADV/DC/AUX/INVERT----
invert logic YES
DOWN YES NO TOP
ADV/DC/PAGE1------------
choose category:
ADV BAT SHUNT PG2
ADV/DC/PAGE2------------
choose category:
PG1 CHARGE AUX PG3
ADV/DC/PAGE3------------
choose category:
PG2 RESET CLR MAIN
ADV/DC/PAGE/RESET-----
reset DC to factory
defaults?
NO YES TOP
ADV/MATE/CLEAR--------
clear data log
memory?
YES NO TOP
ADV/DC/PAGE3------------
choose category:
PG2 RESET CLR MAIN
MATE HBX
MAIN--------------------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
ADV/DC/PAGE3------------
choose category:
PG2 RESET CLR MAIN
ADV/DC/AUX------------
aux parameters
complete
TOP ADV MAIN
ADV----------------------------
choose device:
FX CC DC MATE
ADV/DC/PAGE2------------
choose category:
PG1 CHARGE AUX PG3
ADV/DC/AUX CONTROL--
currently MAN-OFF
DOWN OFF AUTO ON
ADV/DC/CHARGE---------
parameters met time
1 minutes
DOWN INC DEC TOP
ADV/DC/PAGE2------------
choose category:
PG1 CHARGE AUX PG3
