To edit the setup information, use the Up and Down buttons to highlight the section and press
Select.

NOTE:

When Lock Element Addressing is enabled, the drive configuration and load port settings
cannot be changed from the Setup screen.

• To change network settings, use the Up and Down buttons to select Change Network Settings

and press Select. See

Viewing and editing the network settings (standalone libraries or primary

to take the next steps.

• To change the password, use the Up and Down buttons to select Change Password and press

Select. To change the password, enter a 6-digit password using the numbers provided on the
OCP. Press Select to accept the new password. When prompted, re-enter the password to
confirm.

• To enable Lock Element Addressing on a CLM library with 3 or more cabinets, use the Up

and Down buttons to select Lock Element Addressing, then press the Select button. Use the
Up and Down buttons to select Enabled or Disabled, then press the Select button.

• To restore factory settings, use the Up and Down buttons to select Restore Factory Settings,

then press Select. When the confirmation screen appears, select Yes to begin the restoration.

• To enable faster opening of the load ports, use the Up and Down buttons to select Quick

Loadport Open, and then press Select. Use the Up and Down buttons to choose Enable or
Disable, and then press Select. The Open Ports button will appear which you can use to open
the load ports.

• To enable autoclean, use the Up and Down buttons to select Autoclean and press Select. The

default is disabled.

• To enable or disable autounload, use the Up and Down buttons to select Autounload and

press Select, then use the Up and Down buttons to choose Enable or Disable, then press Select.

• To set the barcode length, use the Up and Down buttons to select Barcode Length and press

Select. Next, use the Up and Down buttons to display the appropriate number (from 1 to 9,
or back to 0), then press Select. Default barcode length is 0, which means that a barcode of
any length will be accepted.

• To configure the number of tape drives in the cabinet (when Lock Element Addressing is dis-

abled), use the Up and Down arrows to select the number of drives and press Select.

CAUTION:

If you have a partially filled drive cluster, change the number of tape drives to reflect the
number of installed drives. For example, a cluster with two drives will show as four drives
total with two being inactive. Use the Setup menu to change Configured Drives to 2 instead
of 4, which is the default. This helps avoid potential issues with your application software.

• To enable both load ports (when Lock Element Addressing is disabled), use the Up and Down

arrows to select Both Load Ports, then press Select. The default is disabled.

• To enable the left load port (when Lock Element Addressing is disabled), use the Up and

Down arrows to select Left Load Port (##), then press Select. The default is disabled.

• To enable the right load port (when Lock Element Addressing is disabled), use the Up and

Down arrows to select Right Load Port (##), then press Select. The default is disabled.

• When you are finished viewing/editing the setup information, press Back to return to the

Menu screen.
