Figure 33 Home screen on primary library
.
Figure 34 Home screen on secondary library
.
OCP buttons
At the bottom of each OCP screen are up to five button labels. These labels indicate the functions of
the five push buttons below the OCP. To select a function, press the push button directly below the
button label on the OCP screen.
OCP components
The OCP enables you to perform various functions on the library. Table 8 provides a list of the OCP
functionality available from the Home screen of a standalone library or the Primary cabinet of a Cross
Linked library (see
Figure 32 ).
Table 8 OCP components for a standalone library or the primary cabinet of a Cross Linked system
Options to view or select Displays Screen
Library Name, Date, Model Number, IPv4 Address, IPv6
Interface Id, Configured Slots, Configured Drives, Ports,
Partitioned (primary only), Library State Status Home
Library operations 52
