Table 9 provides a list of the OCP functionality available from the Home screen of a standalone library
or the Primary cabinet of a Cross Linked library (see Figure 34 ).
Table 9 OCP components for a secondary cabinet of a Cross Linked system
Options to view or select Displays Screen
Library Name, Date, Model Number, IP Address, Slots,
Drives, Ports Status Home
Cabinet, Health Status, Setup, Event Log Menu items Menu
Open Left Load Port, Open Right Load Port, Open Both
Load Ports Load Ports Ports
Cabinet
• Online
• Offline
• Details
• Inventory
Drive All
• Reset
• Unthread
• On
• Off
Drive #
• Details
• Reset
• Unthread
• On
• Off
Operations Ops
Robotics Self Test, Individual Axis Self Test, Robotics to
Home Position, Calibrate Cabinet, Read Cabinet Serial
Number, Read Cabinet IEEE Id, Read Cabinet Type, Force
Drive Unload Diagnostics Diags
NOTE:
The STOP button located in the bottom right-hand portion of the OCP is available from every OCP
screen. This button stops the cabinet robot from moving and takes the cabinet offline. To start the
robotics and return the cabinet to the online state, press the Start button.
Menu screen
The Menu screen provides access to contact and cabinet information, as well as providing a way to
set up library information.
To access the Menu screen, press Menu from the Home screen. The OCP displays the Menu screen
(see
Figure 35 ):
