Page 135
Port number in the remote array
9
Group number of the host group or iSCSI target in the remote array
10
LU number in the remote array
11
CU and LDEV numbers in the remote array
12
Journal group number in the remote array
13
Type of volumes in the local array
14
Consistency group number
15
Error level
16
Progress of copy operation or synchronization rate (that is, concordance
rate) between data volume before pair was split and data volume after
pair was split.
17
CLPR number and name
18
NOTE:
If a logical volume is an external LU, # appears after the LDEV number. For more
information about external LUs, see the HP StorageWorks External Storage XP user guide.
To save information in a snapshot file:
1.
If necessary, filter the list (see
Filtering information in the list on the Pair Operation pane
).
2.
In the Pair Operation pane (
), click Snapshot. A confirmation message
appears.
3.
Click OK. A pane appears prompting you to save a snapshot file.
4.
Enter the snapshot file name, and click Save. A confirmation message.
5.
Click OK.
Creating a pair of data volumes (Paircreate)
Using the Paircreate pane, the administrator of the primary array must create pairs of primary and
secondary data volumes. When creating a pair, the administrator can specify options for initial
copy activities.
Before creating one or more pairs, the administrator must ensure that:
•
Volumes to be used as secondary data volumes are offline to all hosts.
•
Ports have already been configured (see
).
•
The primary array is associated with the secondary array (see
Associating primary and remote
arrays and configuring logical paths (Add DKC)
).
After all these points are confirmed, the administrator of the primary array can use the following
procedure to create a pair of a primary and secondary data volume. The administrator of the
secondary array cannot perform this operation.
1.
Ensure that XP Command View Advanced Edition Software or XP Remote Web Console is in
Modify mode. For more information, see the HP StorageWorks XP Command View user guide
for XP Disk Arrays or the HP StorageWorks XP Remote Web Console user guide for
XP12000/XP10000/SVS200.
2.
Display the Pair Operation pane.
3.
In the tree, select a port, host group, or iSCSI target.
4.
In the list, select and right-click the volume you want to use as a primary data volume.
