NOTE:
You can specify the host name instead of the fixed IP address if the fixed IP address and
the corresponding host name are registered in
/etc/hosts
, an NIS server, or a DNS server.
See the NAS Blade Manager User's Guide for information about registering the fixed IP address
and the corresponding host name in
/etc/hosts
and how the NAS Blade system can search
the host name using NIS or DNS.
Based on
, change each entry of
ip_address
in
HORCM_MON
to an appropriate
value. For the entry service in
HORCM_MON
and the entry in
HORCM_CMD
, appropriate values are
specified when NAS Backup Restore is installed.
Change the entries poll and timeout to the appropriate values according to hardware requirements.
Table 38 Example 1: XP RAID Manager configuration definition file (for instance number 16)
HORCM_MON
#ip_address service poll(10ms) timeout(10ms)
123.456.78.51 20331 1000 3000
HORCM_CMD
#dev_name dev_name dev_name
#UnitID 0 (Serial# 62486)
/dev/sdf
HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
# /dev/sdj SER = 62486 LDEV = 70 [ FIBRE FCTBL = 3 ]
VG VG_000 CL1-A-1 0 0
# /dev/sdk SER = 62486 LDEV = 18 [ FIBRE FCTBL = 3 ]
VG VG_001 CL1-A-1 0 1
?
?
# /dev/sdw SER = 62486 LDEV = 66 [ FIBRE FCTBL = 3 ]
VG VG_013 CL1-A-1 0 13
# /dev/sdx SER = 62486 LDEV = 14 [ FIBRE FCTBL = 3 ]
VG VG_014 CL1-A-1 0 14
# /dev/sdy SER = 62486 LDEV = 68 [ FIBRE FCTBL = 3 ]
VG VG_015 CL1-A-1 0 15
# /dev/sdz SER = 62486 LDEV = 16 [ FIBRE FCTBL = 3 ]
VG VG_016 CL1-A-1 0 16
HORCM_INST
#dev_group ip_address service
VG 127.0.0.1 52323
Next, delete unnecessary LU entries (lines) for the
HORCM_DEV
section, except for the LU entry
(line) you want to control using XP RAID Manager (see
).
LUs constituting a file system and their LDEV numbers can be reviewed using the following command.
$ sudo horc_devlist | grep ':File System Name$'
For example, in
, 11, 12, and 13 are LUs constituting the file system sample.
Their LDEV numbers are 64, 12, and 66.
