HP 12000 Virtual Library System EVA Gateway - Manual (Page 193)

Specification Item
20 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); 1 Ports
RJ–45 serial console port; 4 dual-personality ports, each of which can
be used as either an RJ-45 10/100/1000 port or an open mini-GBIC
slot (for use with mini-GBIC transceivers)
MIPS, 264 MHz Processor
16 MB Flash capacity
64 MB SDRAM
0.75 MB Packet buffer size
< 5.6 µs (FIFO 64-byte packets) Latency
up to 35.7 million pps (64-byte packets) Throughput
48 Gbps Switching capacity
8000 entries MAC address table size
164 BTU/hr Maximum heat dissipation
100-127 VAC/200-240 VAC Voltage
1.25 A /0.75 A Current
60 W Power
50/60 Hz Frequency
Ethernet Switch 6600–24G
Specification Item
21.5 x 17.4 x 1.7 in. (54.61 x 44.2 x 4.32 cm) 1U height Dimensions
17.2 lb (7.8 kg) fully loaded Weight
20 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); 1 Ports
RJ–45 serial console port; 4 dual-personality ports, each of which can
be used as either an RJ-45 10/100/1000 port or an open mini-GBIC
slot (for use with mini-GBIC transceivers)
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 256 MB compact
flash, 256 MB DDR SDRAM; packet buffer size: 36 MB QDR SDRAM
total (18 MB for 1 GbE/10-GbE ports) Memory and Processor
< 3.4 μs (FIFO 64-byte packets) 1000 Mb Latency
< 2.4 μs (FIFO 64-byte packets) 10 Gbps Latency
up to 75.7 million pps (64-byte packets) Throughput
101.8 Gbps Routing/Switching capacity
105.6 Gbps Switch fabric speed
10000 entries Routing table size
64000 entries MAC address table size
697 BTU/hr (735.33 kJ/hr) Maximum heat dissipation
100-120/200-240 VAC Voltage
167.6 W Idle power
Ethernet Switch 6600–24G 193
