Installing Hardware Options, Server Power Off
Intel Xeon Processor MP
The ProLiant DL760 G2 server supports either four or eight processors.
• All processors installed on a processor board must be the same speed, cache size,
and stepping. Stepping refers to the processor revision.
• If two processor boards are installed, all processors in both processor boards
must be the same speed, cache size, and stepping.
• Processor 1 must always be installed to properly terminate the processor bus.
Figure 4-1: Processor board layout
Item Description
1
Intel Xeon processor MP in socket 1
2
Intel Xeon processor MP in socket 2
3
Intel Xeon processor MP in socket 3
4
Intel Xeon processor MP in socket 4
4-2
