Configuring the Server
CPU Diagnostic
The CPU diagnostic checks the registers and multiprocessing capability of each of
the system processors. The CPU diagnostic runs two tests on each processor:
• Testing of all the 16-bit and 32-bit registers
• Testing of all the flags for all processors
If there are no processor errors, then “OK” status is displayed next to the processor
information. If there is an error, then an “X” status is displayed next to the processor
information. Figure 8-12 shows a successful processor diagnostic test.
Figure 8-12: CPU diagnostic
