Installing Hardware Options, Hot-Pluggable
Hot-Plug SCSI Hard Drive LED Indicators
The hot-plug SCSI hard drive LEDs, located on each physical drive, are visible on
the front of the server or external storage unit. They provide (1) Activity,
(2) Power/Online, and (3) Fault status for each corresponding drive when configured
as part of an array and attached to a powered-on controller. Their behavior may vary,
depending on the status of other drives in the array.
Figure 5-10: Hot-Plug SCSI hard drive LEDs
For additional information about troubleshooting hard drive problems, refer to the
HP Servers Troubleshooting Guide.
CAUTION: Before removing any hot-plug hard drive, read the important guidelines
in the following two sections.
