Installing Hardware Options, Hot-Pluggable

Installing a Hot-Plug Power Supply

The ProLiant DL760 G2 server ships with two hot-plug power supplies. The system
power in the ProLiant DL760 G2 server does not have to be shut off to replace one of
the power supplies.

WARNING: To reduce the risk of electric shock or damage to the equipment:

Install the power supply before connecting the power cord to it.

Unplug the power cord before removing the power supply from the server.

Disconnect power from the server by unplugging all power cords from
either the electrical outlet or the server.

CAUTION: To prevent data corruption, do not connect the server to a low line power
source (110 VAC). Low line power is not supported.

IMPORTANT: Most system configurations require 200-240 VAC. Use 200-240 VAC line cords
to power the server.

NOTE: A few server configurations may exceed the power rating of a single power supply
resulting in a loss of power redundancy for the server. Use the ProLiant DL760 G2 Power
Calculator available on ActiveAnswers to ensure that power redundancy will be maintained for
your configuration.

5-34

HP ProLiant DL760 Generation 2 Server User Guide

HP CONFIDENTIAL

Writer: Bryce Miller File Name: f-ch5 Installing Options-Hot Pluggable.doc

Codename: Comet Part Number: 201264-001 Last Saved On: 6/17/03 9:47 AM
