Installing Hardware Options, Server Power Off
14. Route the Remote Management cable (30-pin) under the fan support bracket and
connect it to the Remote Management connector (30-pin) on the I/O board as
shown in Figure 4-12.
Figure 4-12: Connecting the internal Remote
Management cable (30-pin)
15. Reinstall hot-plug fan 2.
16. Close the I/O lid.
17. Connect all power cords and power up the server (refer to Chapter 7).
18. Refer to the Remote Insight Lights-Out Edition II User Guide provided on the
Documentation CD for information on configuring the RILOE II option.
