Memory Cartridge Components

The following figure and table show the various components of the memory
cartridges.

Figure 5-2: Memory cartridge components

Item Component

1 Cartridge

lock

2 Cartridge

latch

3 Cartridge

lever

4

Cartridge power LED

5

Cartridge attention LED

HP ProLiant DL760 Generation 2 Server User Guide

5-3
