Installing the Server in a Rack
Shipping Screws
To prevent damage to the processor and memory module during shipping, the server
ships with a shipping screw installed on each side of the chassis. These screws must
be removed, and the processor and memory module must be properly seated and
secured in the chassis before powering up the server.
1. Remove the left and right shipping screws. The shipping screws may look like
(1) or (2) in the following figure.
IMPORTANT: Retain these shipping screws for future use when shipping the server. A
spare set of shipping screws is included with the server.
Figure 2-4: Shipping screws
2. Rotate the module release levers downward.
3. Slide the module into the chassis until the levers begin to rotate.
4. Push the levers upward until they snap into place.
2-12
HP ProLiant DL760 Generation 2 Server User Guide
