Installing Hardware Options, Hot-Pluggable
Replacing Hot-Plug Fans
The ProLiant DL760 G2 server ships with two hot-plug fans. Fan 1 is closest to the
rear of the server. Each fan has the following LED that indicates the status of the fan:
• When the hot-plug fan LED is green, the fan is installed and working properly.
• When the hot-plug fan LED is amber, the fan needs attention or is not installed.
Figure 5-28: Hot-plug fan LEDs
CAUTION: Never remove both hot-plug fans while the server is powered up.
Overheating and damage to hardware could result. If the appropriate HP software
drivers are installed, the operating system software will initiate a power shutdown.
NOTE: The hot-plug fan LEDs are not part of the fan housing.
