Installing Hardware Options, Hot-Pluggable

Table 5-5: I/O Expansion Slots

Slot Description

Slots 1 and 2

Bus 19—Supports PCI-X expansion boards at 100 MHz and 66 MHz or PCI
expansion boards at 66 MHz and 33 MHz; it is keyed for 3.3v signaling.

Slots 3 and 4

Bus 15—Supports PCI-X expansion boards at 100 MHz and 66 MHz or PCI
expansion boards at 66 MHz and 33 MHz; it is keyed for 3.3v signaling.

Slots 5 and 6

Bus 11—Supports PCI-X expansion boards at 100 MHz and 66 MHz or PCI
expansion boards at 66 MHz and 33 MHz; it is keyed for 3.3v signaling.

Slots 7 and 8

Bus 7—Supports PCI-X expansion boards at 100 MHz and 66 MHz or PCI
expansion boards at 66 MHz and 33 MHz; it is keyed for 3.3v signaling.

Slot 9

Bus 0—Supports PCI expansion boards at 33 MHz; it is keyed for 5v signaling.

Slots 10 and 11

Bus 3—Supports PCI-X expansion boards at 100 MHz and 66 MHz or PCI
expansion boards at 66 MHz and 33 MHz; it is keyed for 3.3v signaling.

Note: The operating system detects PCI devices in the following slot order:
9-10-11-7-8-5-6-3-4-1-2.

NOTE: It is recommended that you install the optional RILOE II board into slot 9.

NOTE: Each PCI-X bus will automatically configure to run in the most advanced mode
(PCI-X or PCI) and the highest frequency supported by all expansion boards installed in the
slots on the bus.

NOTE: The ProLiant DL760 G2 server ships with a NIC preinstalled in slot 11.

5-42

HP ProLiant DL760 Generation 2 Server User Guide
