Managing disks

Use the Disk Setup tab to monitor disk information and perform disk management tasks as listed
in

Table 10 (page 39)

.

Table 10 Disk management tasks for storage systems

Model where available

Disk setup function

All

Monitor disk information

Getting there

1.

In the navigation window, select a storage system.

2.

Select the Storage category in the tree below it.

3.

Select the Disk Setup tab.

Reading the disk report on the Disk Setup tab

The Disk Setup tab provides a status report of the individual disks in a storage system.

Figure 11 (page 39)

shows the Disk Setup tab and

Table 11 (page 40)

describes the corresponding

disk report.

Figure 11 Example of columns in the Disk Setup tab

Managing disks

39
