62
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Bit name J0_OOF_ Reserved RX_LAIS_ RX_LRDI_ RX_K1_D K1_UNSTAB RX_K2_D Reserved
D_MASK D_MASK D_MASK _MASK _D_MASK _MASK
R/W R/W — R/W R/W R/W R/W R/W —
Value 1 1 1 1 1 1 1 1
reset
ADDR=0x0FC: Receive LOH Monitor Masks
Bit 7: J0_OOF_D_MASK – J0_OOF delta bit mask
Bit 6: Reserved, always write as one.
Bit 5: RX_LAIS_D_MASK – RX_LAIS delta bit mask
Bit 4: RX_LRDI_D_MASK – RX_LRDI delta bit mask
Bit 3: RX_K1_D_MASK – RX_K1 delta bit mask
Bit 2: K1_UNSTAB_D_MASK – K1_UNSTAB delta bit mask
Bit 1: RX_K2_D_MASK – RX_K2 delta bit mask
Bit 0: Reserved, always write as one.
These bits are used to enable/disable reporting status of the corresponding event bits. If set, reporting status
of the corresponding event bits is disabled.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Bit name Reserved Reserved RX_LOS_D Reserved RX_OOF_D RX_LOF_D_ Reserved Reserved
_MASK _MASK _MASK
R/W — — R/W — R/W R/W — —
Value 0 0 1 0 1 1 0 0
after
reset
ADDR=0x0FD: Receive SOH Monitor Masks
Bits 7-6: Reserved
Bit 5: RX_LOS_D_MASK – RX_LOS delta bit mask
Bit 4: Reserved
Bit 3: RX_OOF_D_MASK – RX_OOF delta bit mask
Bit 2: RX_LOF_D_MASK – RX_LOF delta bit mask
Bits 1-0: Reserved
These bits are used to enable/disable reporting status of the corresponding event bits. If set, reporting status
of the corresponding event bits is disabled.
