6.1.4 Information parameters (P7xx)
Parameters Setting value / Description / Note Device Supervisor
Parameter
set
P700 [-01]
...
[-03]
Present operating status
(Present operating status)
SK 2xxE
0.0 ... 25.4 Display of current messages for the present operating status of the frequency inverter such as
errors, warnings or the reason why switch-on is disabled. For details of the messages, see BU
0200.
[-01] = Present fault, shows the currently active (unacknowledged) fault.
[-02] = Present warning, indicates a current warning message.
[-03] = Reason for disabled starting, indicates the reason for an active start disable.
NOTE
SimpleBox/ControlBox: with the SimpleBox or ControlBox only warning messages and errors
can be displayed. Display of the messages is in encoded form.
ParameterBox: with the ParameterBox the messages are displayed in plain text. In addition, the
reason for a possible disabling of starting can also be displayed.
Bus: The display of bus-level error messages is made in decimal integer format. If this value is
divided by 10, the display corresponds to that in the SimpleBox or ControlBox.
Example: Display: 20 → Error number: 2.0
P701 ... [-01]
...
... [-05]
Last fault 1..5
(Last fault 1 ... 5)
SK 2xxE
0.0 ... 25.4 This parameter stores the last 5 faults. Further details are described in the frequency inverter
manual (BU0200).
With the SimpleBox the corresponding memory location 1...5 (Array parameter), must be
selected and confirmed with the ENTER key in order to read the stored error code.
P740 ... [-01]
…
... [-13]
Process data bus In
(Process data bus in)
SK 2xxE S
0000 ... FFFF (hex) This parameter provides information about the actual control word (STW) and the setpoints
(SW1-3) that are transferred via the bus systems.
For values to be displayed, a bus system must be selected in P509.
… [-01 ] = Control word Control word, source from P509.
… [-02] = Setpoint 1 (P546 [-01])
… [-03] = Setpoint 2 (P546 [-02])
… [-04] = Setpoint 3 (P546 [-03])
Setpoint data from main setpoint P510 - 01.
… [-05 ] = Bus I/O In bits (P480)
The displayed value depicts all Bus In bit sources
linked with OR.
… [-06 ] = Parameter data In 1
… [-07 ] = Parameter data In 2
… [-08 ] = Parameter data In 3
… [-09 ] = Parameter data In 4
… [-10 ] = Parameter data In 5
Data during parameter transfer: Order label
(AK), Parameter
number (PNU), Index (IND),
Parameter value (PWE 1/2)
… [-11 ] = Setpoint 1
… [-12 ] = Setpoint 2
… [-13 ] = Setpoint 3
Setpoint data from master function value
(Broadcast), if P509/510 = 4 (P502/P503)
