5.2.2 Data records
5.2.2.1 Data records 100 to 104
The data records are written to Slot 0. The number of the data record determines the relevant target device.
For this:
DS 100 
Access to the technology unit (parameter range 150…199)
DS 101  Access to the frequency inverter 1 (parameter range 0 … 999, except 150…199)
…
DS 104 
Access to the frequency inverter 4 (parameter range 0 … 999, except 150…199)
NOTE
The inverter parameters are mapped in the range 1000 to 1999, i.e. 1000 must be added to the
parameter number for parameterisation (e.g. (P508) - P1508).
Field Data size Explanation
Parameter number
and
order label
2 Bytes FI or SK TU4 parameter
The parameter number is a 16 Bit value (+1000) and can be obtained from
the relevant operating manual for the frequency inverter or technology unit.
The order label is added to the parameter number. (upper Nibble)
Parameter index 2 Bytes Parameter sub-index (see Section 5.2.3.2)
Parameter value 4 Bytes New setting value (See Section 5.2.3.3).
Table 21 Structure of data records 100 and 101
5.2.2.2 Data record 47
This data record is written to Slot 0 and is then assigned to the relevant device on the basis of the axis. The
format is compliant withe the ProfiDrive profile.
Field Data size Explanation
Order reference 1 Byte The order reference is transferred from the IO controller and is used for the
definitive allocation of the SK TU4-PNT response
Order label 1 Byte Read / write parameter value etc. (see Section 5.2.3.1)
Axis 1 Byte Access to SK TU4-PNT parameter or FI parameter
0 = SK TU4-PNT
1 = Frequency inverter 1
2 = Frequency inverter 2
3 = Frequency inverter 3
4 = Frequency inverter 4
Parameter number 2 Bytes FI or SK TU4 parameter
The parameter number is a 16 Bit value (+1000) and can be obtained from
the relevant operating manual for the frequency inverter or technology unit.
Parameter index 2 Bytes Parameter sub-index (see Section 5.2.3.2)
Parameter value 4 Bytes New setting value (See Section 5.2.3.3).
Table 22 Structure of data record 47
